Melexis MLX90614 Plug & Play Thermometer in a TO-can

Melexis MLX90614 Digital Plug and Play Infrared Thermometer in a TO-can is an Infrared thermometer for non-contact temperature measurements. The MLX90614 integrates both the IR sensitive thermopile detector chip and the signal conditioning ASIC into the same TO-39 can.

Installed in the MLX90614 are a low-noise amplifier and 17-bit ADC and powerful DSP. This enables the high-accuracy and resolution of the thermometer. The MLX90614 comes factory calibrated with a digital SMBus output that gives full access to the measured temperature in the complete temperature range(s) with a resolution of 0.02°C.

The digital output can be configured to be PWM. The 10-bit PWM is configured to continuously transmit the measured temperature in the range of -20 to 120°C, with a 0.14°C output resolution.

Features

Factory calibrated IR thermometer with linear digital output
Small size TO-39 can, easy to integrate
Standard calibration in wide temperature range:
- -40°C to +125°C for ambient temperature
- -70°C to+ 380°C for object temperature
Better than 0.5°C accuracy in the range 0 to 50°C
0.01°C readout resolution possible
High refresh rate
Easy emissivity correction
Continuous temperature readout through PWM (Pulse Width Modulated) output
2-wire SMBus compatible interface for reading temperatures and sensor reconfiguration

Building block for sensor network with up to 100 thermometers
High-reliability and long-term stability
Available for 3V and 5V applications, easy to adapt for voltage sources in the range of 6V to 24V
Power saving mode for battery operation
Unique ID numbers in memory provide traceability
Single- or dual-zone thermometer versions available
RoHS compatible

Applications

High-precision contact-less temperature measurement;
Thermal Comfort sensor for Mobile Air Conditioning control system
Windshield defogging
Automotive blind angle detection
Temperature sensing element for residential, commercial and industrial building air conditioning
Presence detector
Fire/heat detection, alarm systems
Mobile telephones
