Alpha Wire EcoFlex® PUR Flex Cable

Alpha Wire EcoFlex® PUR Flex Cable provides more than 8 million flex cycles in tough application conditions while saving space and reducing weight. These cables are up to 40% smaller and 44% lighter than traditional flex cables while resisting oil, solvents, UV radiation, and abrasion. Alpha Wire EcoFlex PUR cables remain flexible at low temperatures and are available in a variety of conductor sizes and counts with shielded and unshielded versions.

Features

More than 8 million flex life cycles
Resists oil, solvents, UV radiation, and abrasion
No halogens, phthalates, or heavy metals
Bend radius
- Static: 4x
- Dynamic: 6x

Two to 36 conductors
Unshielded or braid shielding
28AWG to 10AWG
Operating temperature
- -50°C to +90°C (static)
- -40°C to +80°C (dynamic)

Approvals

• UL AWM 21959 (90°C, 600V_RMS)
• UL Oil Res I
• UL sunlight resistant
• CSA AWM I/II A/B FT2
• IEC60228 Conductors, Class 6
• EU Low Voltage Directive 2006/95/EC
• IEC 60332-1 and 60332-2 flame behaviors
• IEC60754-2 acid gas generation
